Name: CYBERPOWER Online S 10000VA/10000W 5U Rackmount UPS - 12V/9AH*20 - Hardwire Terminal Block- (OLS10KERT5U), 2 Yrs Adv. Replacement WTY
Brand: CyberPower
SKU: 1999216
Price: 5886 AUD
Availability: InStock

Description

CYBERPOWER Online S 10000VA/10000W 5U Rackmount UPS - 12V/9AH*20 - Hardwire Terminal Block - (OLS10KERT5U),2 Yrs Adv. Replacement WTY

Tech specs

Power	10000VA

Full specification

Specifications:

Phase: Single Phase
Form Factor: Rackmount / Tower
UPS Topology: Online Double Conversion
Energy Saving Technology: Online ECO Mode Efficiency > 98%
Active PFC Compatibility: Yes
Generator Compatibility: Yes
Nominal Input Voltage ( Vac ): 230
Input Voltage Range ( Vac ): 110 - 300
Adjustable Voltage Range ( Vac ): 0-50% Load for 110 - 144 Vac | 0-75% Load for 145 - 179 Vac | 0-100% Load for 180 - 300 Vac
Input Frequency ( Hz ): 50 - 60Hz
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 49.5
Input Power Factor: 0.99
Input Connector Type: Hardwire Terminal Block
Capacity (VA): 10000
Capacity (Watts): 10000
On Battery Waveform: Pure Sine Wave
On Battery Frequency ( Hz ): 50 ± 0.5% | 60 ± 0.5%
Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse
Overload Protection (Line Mode): 105-130% Load for 10 sec, >130% Load for 1.5 sec
Overload Protection (Battery Mode): 105-130% Load for 10 sec, >130% Load for 1.5 sec
Overload Protection (Bypass Mode): 110-120% Load for 30 min, 120-130% Load for 2 min, 130-150% Load for 15 sec, >150% Load Immediately
Harmonic Distortion (Linear Load): THD?1.5%
Harmonic Distortion (Non-linear Load): THD?3%
Internal Bypass: Automatic Bypass / Manual Bypass
Maintenance Bypass: Yes
Outlet(s) - Total: 9
Outlet Type: Hardwire Terminal Block x 1 | IEC C13 x 4 | IEC C19 x 4
Typical Transfer Time ( ms ): 0
Runtime at Half Load ( min ): 11.2
Runtime at Full Load ( min ): 2.9
Typical Recharge Time ( Hours ): 4
Maximum Charging Current ( A ): 4
Adjustable Charging Current ( A ): 1 - 4
Start On Battery: Yes
Smart Battery Management (SBM): Yes
User-replaceable: Yes
Hot-swappable: Yes
Compatible Extended Battery Module (EBM): BPS240V9ART3U
Max. EBM Quantity ( pcs ): 10
Surge Suppression ( Joules ): 1335
EMI/RFI Filtration: Yes
LCD Orientation: Rotatable LCD Manual
Tiltable LCD Panel: 15 degrees
HID Compliant USB Port(s): 1
Serial Port: RS232
Dry Contact (with Relay): Yes
Emergency Power Off (EPO) Port: Yes
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Remote Cloud Card: Yes - Built-in Remote Cloud Card by Ethernet included
Enclosure Construction: Metal
Rackmount Rail: Yes
Rackmount Ears: Yes
Dimensions: 433 x 213.5 x 661mm
Weight: 80kg
Installed Rack Height ( U ): 5
Online Thermal Dissipation ( BTU/hr ): 2047
Audible Noise at 1.0M from Surface of Unit: 62 dBA
Certifications: CE / RoHS
