Specification
Frequency Range: 57–66 GHz
Channel Width: 2.16 GHz, 4.32 GHz (with carrier bonding)
Maximum Throughput: 15.2 Gbps (7.6 Gbps uplink, 7.6 Gbps downlink) with channel bonding
Coverage: Dual-sector with 280° beamforming
Channel Access: TDMA/TDD
Mode of Operation: PTP, PMP, Mesh
Ethernet Interface: 1× 10G BaseT PoE In, 1× 1G BaseT 802.3at PoE Out, 1× SFP+ (1G/10G)
Protocols: IPv4, IPv6, Layer 2 Bridge, Layer 3 Routing
Management: cnMaestro (cloud or on-premises), HTTP, HTTPS, SNMP v2c & v3
Security: 128-bit AES encryption
Antenna Gain: 44.5 dBi with beamforming
Maximum Connections: 30 client nodes or 4 distribution nodes
Certification: Facebook Terragraph, 802.11ay
