CyberPower Smart App Office Rackmount Series LCD 1000VA / 600W 1U Line Interactive UPS(OR1000ERM1U) 2 Yrs Adv. Rep & 2yrs on Int. Battery
1 / 2
CyberPower
CyberPower Smart App Office Rackmount Series LCD 1000VA / 600W 1U Line Interactive UPS(OR1000ERM1U) 2 Yrs Adv. Rep & 2yrs on Int. Battery
MPN:
OR1000ERM1U
$716.00
$829.00
Inc GST
In stock: 38 available
−
+
38 available
Buy it now
Add to cart
View other CyberPower products →
Details
Specs
1
More information
Similar items
12
Description
GENERAL UPS Topology: Line-Interactive Energy Saving: GreenPower UPS™ Bypass Technology INPUT Voltage: 230Vac Input Voltage Range: 160Vac - 270Vac Input Frequency Range: 50/60Hz ± 3Hz (Auto-sensing) Plug Type: IEC 320 C14 OUTPUT VA: 1000 Watts: 600 On Battery Waveform: Simulated Sine Wave On Battery Voltage: 230Vac ± 10% Automatic Voltage Regulation (AVR): Single Boost On Battery Frequency: 50/60Hz ± 1% Outlets - Total: 6 Outlet Type: IEC 320 C13 Outlets - Battery & Surge Protected: 4 Outlets - Surge-Only Protected: 2 Transfer Time: 4-8ms(typical) BATTERY Runtime at Half Load (min): 14 Runtime at Full Load (min): 3.5 Battery Type: Sealed Lead Acid User Replaceable: Yes Hot-Swappable: Yes Typical Recharge Time: 8 hrs Replacement Battery Pack: RBP0025 Replacement Battery Pack Quantity:1 PHYSICAL Form Factor: Rack PHYSICAL - UPS MODULE Dimensions (WxHxD) (mm.): 433 x 44 x 389 Weight (kg.): 13.7 Installed Rack Height: 1U
Tech specs
Power
1000VA
Full specification
Specifications:
Phase: Single Phase
Form Factor: Rackmount
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Nominal Input Voltage ( Vac ): 230
Input Voltage Range ( Vac ): 165 - 271
Adjustable Voltage Range ( Vac ): 253 - 271 Vac | 189 - 207 Vac
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 10
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: IEC C14 x 1
Power Cord Length: 1.83m
Capacity (VA): 1000
Capacity (Watts): 600
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10 %
On Battery Frequency ( Hz ): 50 ± 10% | 60 ± 10%
Power Factor: 0.6
Automatic Voltage Regulation (AVR): Single Boost
Overload Protection: Internal Current Limiting | Circuit Breaker
Outlet(s) - Total: 6
Outlet Type: IEC C13 x 6
Outlet(s) - Battery & Surge Protected: 4
Outlet(s) - Surge-Only Protected: 2
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 14
Runtime at Full Load ( min ): 3.5
Typical Recharge Time ( Hours ): 8
Start On Battery: Yes
User-replaceable: Yes
Hot-swappable: Yes
Replacement Battery Pack (RBP): RBP0025
Replacement Battery Pack (RBP) Quantity ( pcs ): 1
Surge Suppression ( Joules ): 810
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in | 1-out
LCD Information Display: Operation Type | Power Status | Battery Status | Load Status | Other Information
LCD Setting & Control: Mode Setting | Alarm Setting | Input & Output
LED Indicators: Power On
HID Compliant USB Port(s): 1
Serial Port: Dry Contact
Audible Alarms: Battery Mode | Low Battery | Overload | UPS Fault
Management Cable ( pcs ): Power Cord x4 | USB Cable x1
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Enclosure Construction: Metal
Rackmount Ears: Yes
Dimensions: 433 x 44 x 389mm
Weight: 13.7kg
Installed Rack Height ( U ): 1
Online Thermal Dissipation ( BTU/hr ): 24
Certifications: CE | EAC | RCM | RoHS
Warranty: 2 Years
Features:
Line-interactive UPS Topology
Simulated Sine Wave Output
Overload Protection
Surge and Spike Protection
Phone/Fax/Modem/DSL/Network Protection
USB Connectivity Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Automatic Voltage Regulation (AVR)
Hot-swappable Batteries
EMI and RFI Filtration
LCD Status Display
PowerPanel Management Software
What's in the box?
1 x OR1000ERM1U UPS
1 x Rackmount Ears
1 x Power Cord
1 x USB Cable
1 x User Manual
