Description
The Cisco ASR-9006-DC-V2 is a powerful and compact 6RU router chassis from the industry-leading Cisco ASR 9000 Series Aggregation Services Routers, engineered for high-performance edge and core network deployments. It supports two line card slots, dual route processor slots, and redundant DC PEM V2 power modules, delivering high availability and continuous service with Cisco IOS XR software.</description>
<parameter name="specification">Chassis: 6RU compact form factor
Height: 17.5 inches
Width: 17.5 inches
Depth: 28.65 inches
Power: DC modules (1.5 kW or 2.1 kW options)
Power Input: Worldwide DC (-40 to -72V; 50A nominal, 60A maximum)
Operating Temperature: -5 to 55°C (23 to 131°F)
Operating Humidity: 5 to 90% relative humidity
Line Card Slots: 2
Route Processor Slots: 2 (dual/redundant)
VLAN Support: up to 4096
Operating System: Cisco IOS XR
Routing Protocols: BGP, OSPF, EIGRP, IS-IS
Features: IPv6 support, Synchronous Ethernet (SyncE), Hierarchical QoS (H-QoS), Nonstop forwarding, EOAM, BFD
