The N3K-C3172TQ-32T is a Cisco Nexus 3172TQ Layer 2/3 managed network switch with 32 10GBase-T ports and 6 QSFP+ ports, designed for high-density data center and enterprise deployments. The -24X7X4 suffix indicates a Cisco SMARTnet support plan providing 24/7 availability with 4-hour hardware replacement.
32 x 10GBase-T RJ-45 ports
6 x QSFP+ ports (supports 40GbE or 4x10GbE breakout)
1.4 Tbps switching capacity
1 Bpps forwarding rate
288,000 MAC address table entries
1 RU form factor
Dimensions: 4.4 x 43.9 x 50.5 cm (H x W x D)
Weight: approximately 10 kg
Operating temperature: 0–40°C
Cisco NX-OS software
Layer 2 and Layer 3 switching
Front-to-back airflow
AC and DC power inputs available
