Category: 6A
Type: UTP (Unshielded Twisted Pair)
Length: 305 m (1,000 ft)
Flame Rating: CMR (Riser)
Conductor: 23 AWG solid bare copper
Jacket Material: Flame retardant polyvinyl chloride (FRPVC)
Jacket Diameter: 7.05 ± 0.2 mm
Jacket Color: White
Shielding: UTP
Anti-Crosstalk Divider: Yes
Ripcord: Yes
Data Rate: Up to 10 Gbps (10GBase-T) up to 100 m
Bend Radius: Min. 28.2 mm (1.11")
Installation Temperature: 0 to 60°C (32 to 140°F)
Operating Temperature: -20 to 75°C (-4 to 167°F)
Standards: ANSI/TIA-568.2-D, ISO/IEC 11801-1 (Edition 2.2), IEC 61156-5 (Edition 2.1), UL 1666
Box Dimensions: 494 x 302 x 481 mm (19.4 x 11.9 x 18.9")
Box Weight: 19.3 kg (42.5 lb)
