Full specification
Socket AM5 for AMD Ryzen 9000/8000/7000 series processors
AMD B850 Chipset
4x DIMM slots, max. 256GB DDR5 memory
4x M.2 slots (M.2_1: PCIe 5.0 x4 for Ryzen 9000/7000, M.2_2 to M.2_4: PCIe 4.0)
2x SATA 6Gb/s ports
14+2+2 power stages
WiFi 7 (802.11be) with 2.4/5/6GHz support
Realtek 5G Ethernet
ROG SupremeFX audio with ALC4080 codec and Savitech SV3H712 amplifier
PCIe 5.0 x16 and PCIe 4.0 x16 expansion slots
USB connectivity: 1x USB 20Gbps Type-C, 3x USB 10Gbps, 4x USB 5Gbps, 2x USB 2.0
1x HDMI port, 1x DisplayPort
ATX form factor (30.5cm x 24.4cm)
64MB BIOS with integrated Wi-Fi driver
