A 2-wire IP distributor with 6 cascade interfaces for connecting door stations and supporting device power supply, 2 cascade interfaces for cascading additional distributors, Din rail mounting, and 24VDC power.
Specification
2-wire IP distributor
6 × 2-wire cascade interfaces with device power supply
1 interface (max. 16W) for door station connection
2 cascade interfaces for DS-KAD706/DS-KAD706-S
8 interface indicators for signal display
1 RJ-45 network interface
1 reset button
Din rail mounting
Power supply: 24VDC
Power consumption: 9W
Working temperature: -10°C to +40°C
Working humidity: 10% to 90%
Dimensions: 143.7mm × 92.4mm × 65.9mm
