Full specification
Firewall Throughput: 164 Gbps (IPv4), 163 Gbps (IPv6) @ 1518-byte UDP
Firewall Throughput: 229.5 Mpps (packets per second)
IPsec VPN Throughput: 55 Gbps
IPS Throughput (Enterprise Mix): 42 Gbps
NGFW Throughput (Enterprise Mix): 31 Gbps
Threat Protection Throughput: 30 Gbps
Concurrent Sessions: 16 million
Interfaces: 4x 25G SFP28, 4x 10GE SFP+, 8x 1GE SFP, 17x GE RJ45 (16x switch, 1x MGMT), 1x 2.5G HA RJ45
Processors: NP7 (Network Processor), CP9 (Content Processor) hardware acceleration
Power: Dual AC PSU, 100-240VAC, 50/60 Hz
Form Factor: 1RU Rack Mount
Dimensions: 1.5 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight: 7.25 kg (15.98 lbs)
Operating Temperature: 0°C to 45°C (32°F to 113°F)
