The Vertiv Liebert GXT5-EBC72VRT2U is an external hot-swappable, lead-acid UPS battery cabinet designed for use with Liebert GXT5 UPS models, with auto-detection feature making installation easy and fast. Users can connect up to 10 external battery cabinets to a single UPS for extended runtime.
Tech specs
Capacity
9.0Ah per cell
Form factor
2U rackmount/tower
Full specification
Voltage: 72V DC
Battery Type: Valve-regulated, non-spillable, flame-retardant lead acid
Battery Configuration: 2 × 3 × 12V × 9.0Ah
Weight: 39 kg (85.8 lb)
Dimensions: 430mm W × 85mm H × 540mm D
Form Factor: 2U rackmount/tower convertible
Operating Temperature: +32 to +104°F (0 to 40°C)
Battery Life: 3 Year Minimum, 5 Year Maximum
Recharge Time: 3 Hours
Interface: Auto-detection of external battery cabinets
