The R260 is a newly designed short-depth 1-socket rack server tailored for SMB and Near-Edge customers, offering the power and flexibility to keep them at the forefront of technology. Featuring the latest Intel Xeon-E 2400 series processors, DDR5 memory, NVMe BOSS, and Energy Star 4.0 PSU, it delivers enterprise-level capabilities in a compact form factor.
1U rack-mount server, single-socket form factor
Intel Xeon E-2400 series processors (up to 8 cores) or Intel Pentium G7400/G7400T (up to 2 cores)
4 DDR5 UDIMM slots, up to 128GB, speeds up to 4400MT/s
2 x 3.5-inch cabled SAS/SATA HDD (max 32TB) or 6 x 2.5-inch hot-plug SAS/SATA HDD/SSD (max 46.08TB)
BOSS-N1 boot optimisation support
iDRAC9 management with Lifecycle Controller
Embedded Broadcom 5720 dual-port 1Gb networking
2 x PCIe Gen4 expansion slots (1x8 and 1x8 connectors)
12 Gbps SAS3 and 6 Gbps SATA support
Short-depth 17-18 inch chassis for near-edge deployment
