Tp-Link Omada Pro 24-Port Managed 2.5G L3 Switch, 2.5G (24), SFP28(4), 1U, 5YR

The TP-Link Omada Pro S6500-24M4Y is a 24-port 2.5G Layer 3 managed stackable switch with 4× 25G SFP28 uplink slots, delivering 320 Gbps switching capacity. It features physical stacking capability for up to 12 units, advanced routing protocols (OSPF, BGP, IS-IS), and centralised cloud management via Omada Pro SDN platform.

24× 2.5 Gbps RJ45 ports 4× 25 Gbps SFP28 slots 320 Gbps switching capacity 238.1 Mpps packet forwarding rate 160 Gbps forwarding bandwidth L3 managed switch with OSPF, BGP, IS-IS, VRRP, PIM-SM/PIM-DM/PIM-SSM, ECMP, PBR Stacking: up to 12 units (standalone), 4 units (Omada controller mode) 4GB DDR4 DRAM Dual-Core ARM @1.5GHz CPU 3 MB packet buffer 32K MAC address table 9 KB jumbo frame support Redundant power supply (PSM550-AC or PSM900-AC modules) 1U form factor Physical dimensions: 1U rackmount Management: Web GUI, CLI, Omada app Security: MACsec, Secure Boot, 802.1X, Port Security Operating voltage: 100-240V, 50/60 Hz
