Full specification
Socket: LGA 1700
Chipset: Intel B760
Form Factor: Micro-ATX (mATX)
Memory: DDR5-7200/6800/6600/6400/6200/6000/5800/5600/5400/5200/5000/4800
Storage: 2x M.2 slots (PCIe 4.0)
Power: 12+1 DrMOS (50A+60A) power stages
Rear I/O: 1x USB 3.2 Gen 2x2 Type-C, 2x USB 3.2 Gen 2 Type-A, 3x USB 3.2 Gen 1 Type-A, 2x USB 2.0 Type-A
Front I/O: 1x USB 3.2 Gen 2 Type-C connector, 1x USB 3.2 Gen 1 header, 2x USB 2.0 headers
Audio: Realtek 7.1 Surround Sound (24-bit/192kHz)
Networking: Intel Wi-Fi 6 (802.11ax), 2.5Gb Ethernet, Bluetooth v5.2
Video: HDMI, DisplayPort
Expansion: PCIe 5.0 x16, PCIe 4.0 x4 (M.2), Thunderbolt 4 (USB4) support
Cooling: M.2 and VRM heatsinks
Additional: BIOS Flashback, SafeSlot Core+, TUF Chokes protection
