Single output power: 20 W
Input voltage range: 85 - 264 VAC 47 - 63 Hz
DC output voltage: 12 V
DC output current: 0 - 1.67 A
Output ripple and noise: 120 mVp-p
Line regulation: ±1 %
Load regulation: ±1 %
Efficiency: 80 %
Adjustable range for DC voltage: ±1 %
35 mm DIN rail mounting
Dimensions: 22.5 x 90 x 100 mm
Weight: 0.190 kg
Overload protection
Overvoltage protection
