Lenovo ThinkSystem DE2000H 24 x Total Bays DAS/SAN Storage System - 2U Rack-mountable

The Lenovo ThinkSystem DE2000H 7Y71A00QWW is a low-cost hybrid entry-level DAS/SAN storage array in a 2U form factor supporting 24 small form-factor (2.5-inch) drives or SSDs. It features dual active/active Gen2 controllers with 8GB cache per controller, RAID support (0, 1, 3, 5, 6, 10), and flexible connectivity options including iSCSI, Fibre Channel, and 12Gb SAS.

Form Factor: 2U Rack-mountable Drive Bays: 24 x 2.5" SFF (Small Form Factor) Controllers: 2x Gen2 Controllers with 8GB cache each (16GB total base) Memory: Expandable to 32GB per controller (64GB total) RAID Levels: 0, 1, 3, 5, 6, 10 Connectivity: 10/25 Gb iSCSI SFP28, 8/16/32 Gb FC, 12 Gb SAS, or 1/10 Gb iSCSI RJ-45 Maximum Capacity: 1.47 PB raw storage (with expansion enclosures) Power: 2x 913W redundant hot-swap power supplies (100-240V AC, Platinum efficiency) Features: Dynamic Disk Pools, 128 snapshots, Volume Copy, Thin Provisioning, SSD Read Cache Performance: Up to 100,000 random read IOPS, 35,000 random write IOPS, 3 GBps sequential read, 0.9 GBps sequential write Supported Drives: SSDs 3.84-15.36TB, HDDs 1.2-1.8TB 10K rpm, FIPS-encrypted options Dimensions (2U24): 85mm H x 449mm W x 553mm D Weight: 24.59 kg (fully configured, no drives)
