CyberPower 1U 10amp Metered Automatic Transfer Switch-(PDU24004) – 12x IEC C13 out – IEC 320 C14*2 in - 2 Yrs Adv. Replacement Wty-(No SNMP network function
1 / 4
CyberPower
CyberPower 1U 10amp Metered Automatic Transfer Switch-(PDU24004) – 12x IEC C13 out – IEC 320 C14*2 in - 2 Yrs Adv. Replacement Wty-(No SNMP network function
MPN:
PDU24004
$817.00
$939.00
Inc GST
Available to order
−
+
Buy it now
Add to cart
View other CyberPower products →
Details
Specs
2
More information
Similar items
12
Description
CyberPower 1U 10amp Metered Automatic Transfer Switch-(PDU24004) – 12x IEC C13 out – IEC 320 C14*2 in - 2 Years Advanced Replacement Warranty - (No SNMP network function)
Tech specs
Form factor
Rackmount
Colour
Black
Full specification
Specifications:
Phase: Single Phase
Dual Power Inputs: Yes
Nominal Input Voltage ( Vac ): 200 - 240
Input Frequency ( Hz ): 50 / 60
Maximum Input Current ( A ): 12 (UL) | 10 (CE)
Overload Protection: Circuit Breaker
Input Connector Type: IEC C14 x 2
Power Cord Length: 3.05m
Output Voltage ( V ): Depends on Input
Outlets - # of Bank(s): 1
Outlet(s) - Total: 12
Outlet(s) - Rear: 12
Outlet Type: IEC C13 x 12
LCD Information Display: Input Voltage (Volts) | Input Frequency (Hz) | Current Level (Amps) | Power Consumption (Kilowatts) | Serial Number | Hardware Version | Firmware Version
Hot-swappable LCD Module: Yes
LCD Setting & Control: Preferred Source | Source Configuration | Load Configuration | LCD Settings | Reset / Reboot
LED Indicators: PDU Status | Source Status | Load
Connectivity Port: RJ45 (for Serial)
User-upgradeable Firmware: Yes
Installed Rack Height (U): 1
Form Factor: 1U Horizontal Rackmount
Enclosure Construction: Steel
Cord Retention Tray: Yes
IEC Receptacle Locking: Yes
External Site Ground Pin: Yes
Adjustable Mounting Brackets: 1 Set
Dimensions: 433 x 44 x 215mm
Weight: 3.5kg
Certifications: CE | FCC Class A | UL62368 | EN 55032 Class A | IEC 62368 | RoHS
Features:
Real-time Local Monitoring
Quick Transfer Time (Total < 10 ms)
Digital Real-time Load Display
Hot-swappable LCD Design
Firmware Upgrade via USB
Adjustable Mounting Brackets
IEC Receptacle Locking
Dual Inputs
Industrial-grade Metal Housing
User Configurable Color LCD
LED Status Indicator
User-upgradeable Firmware
Cord Retention Tray
What's in the box?
1 x PDU24004
1 x User Manual
1 x Cord Retention Tray
1 x Mounting Brackets
1 x Cable Ties
1 x Screw Kit
1 x Power Cord
1 x Serial Cable
