Full specification
Processor: Intel Xeon Silver 4314 (3rd Gen, 16-core, 2.4 GHz, 3.4 GHz turbo, 24 MB L3 cache, 135W)
Memory: 32 GB DDR4 RDIMM (3200 MT/s rated, 2933 MT/s effective), 8-channel, up to 2 TB max supported
Storage Controller: HPE Smart Array MR416i-p with 4 GB cache and Smart Storage Battery
Drive Bays: 8x SFF (2.5-inch) hot-swap bays, Tri-Mode 24G U.3 BC backplane
Network: Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ OCP3 Adapter (NC = Networking Choice, no embedded networking)
Power Supply: 1x 800W Flex Slot Platinum Hot Plug Low Halogen
Cooling: 6 fans – Maximum Performance
Management: HPE iLO 5
Security: TPM (Trusted Platform Module)
Form Factor: 2U Rack-mountable
Dimensions: 8.75 H x 44.54 W x 71 D cm
Weight: 63.43 lbs (approximately 28.8 kg)
Chipset: Intel C621a
PCIe: 3 slots (x8/x16/x8)
Warranty: 3/3/3
