Full specification
Interface: 12Gb/s SAS / 6Gb/s SATA
Form Factor: Low-profile PCIe (standard slot installation)
PCIe: 3.0 x8
Cache: 2GB Flash-Backed
Ports: 8 Internal SAS/SATA (via 2x Mini-SAS HD x4 SFF-8643 connectors)
RAID Levels: 0, 1, 5, 6, 10, 50, 60, RAID 1 Triple, RAID 10 Triple, JBOD
Drive Support: Supports intermixing 24Gb/s, 12Gb/s, and 6Gb/s SAS drives; SATA drives; SSDs
Max Arrays: 64
Max Logical Drives: 64
Max LUN Size: Greater than 2TB
Chipset: Microchip Luxor ROC PM8204
Dimensions: 167mm (6.6 inches) length
Operating System Support: Windows Server 2016/2019, RHEL 7.9/8.2/8.3, SUSE SLES 12 SP5/15 SP2, Ubuntu 18.04/20.04 LTS, VMware vSphere 6.7/7.0
Warranty: 1-year limited
