(LS)Simplecom SA221 USB 3.0 to mSATA + NGFF M.2 (B Key) SSD 2 in 1 Combo Adapter

Simplecom SA221 is a 2 in 1 Combo Adapter for both M.2 and mSATA SSD to SATA and USB 3.0 interface. Use this adapter to easily access 6 different size M.2 or mSATA SSDs via standard SATA or USB 3.0 port. It’s an ideal solution for data backup and migration. Specifications mSATA + M.2 SSD 2 in 1 Combo Adapter Detachable USB 3.0 cable, with SATA and USB 3.0 dual interface LED indicates power and activity status Support SATA Revision 3.2 PCI Express M.2 Spec. Revision 0.7, Version 1.0 PCI Express Mini Card Electromechanical Spec. 1.2 B Key M.2 interface, support B Key or B+M Key M.2 SSD Thermal shutdown protection Short circuit protection In-rush current suppression PWM synchronous buck converter Power IC Support following form factor M.2(NGFF) SSD: Type 2230-D2-B-M: 30mm(L) x 22mm(W) Type 2242-D2-B-M: 42mm(L) x 22mm(W) Type 2260-D2-B-M: 60mm(L) x 22mm(W) Type 2280-D2-B-M: 80mm(L) x 22mm(W) Support following form factor mSATA SSD: Half size mSATA : 26.8mm(L) x 30mm(W) Full size mSATA : 50.95mm(L) x 30mm(W) Note: If both M.2 & mSATA SSD inserted at the same time the M.2 SSD will take priority. The mSATA SSD will be disabled until the M.2 SSD is removed. The M.2 interface is B Key, M Key only or NVMeM.2 SSD are not supported. Package Contents 1x mSATA + M.2 SSD to SATA 2 in 1 Combo Adapter 1x USB 3.0 Cable <img alt='' src='http://www.simplecom.com.au/media/wysiwyg/sa221_main.jpg'>

2-in-1 mSATA + M.2 SSD Combo Adapter Detachable USB 3.0 cable with SATA and USB 3.0 dual interface USB 3.0 SuperSpeed 5Gbps data transfer Supports SATA Revision 3.2 PCI Express M.2 Spec. Revision 0.7, Version 1.0 B Key M.2 interface (B Key or B+M Key M.2 SSDs supported) Supports M.2 form factors: 2230, 2242, 2260, 2280 Supports mSATA: half size (26.8mm x 30mm) and full size (50.95mm x 30mm) LED power and activity status indicator Thermal shutdown, short circuit, and in-rush current protection PWM synchronous buck converter Power IC Package: 1x Adapter, 1x USB 3.0 Cable
