Frequency Range: 4.9 GHz to 5.97 GHz
Gain: 17 dBi
3 dB Beamwidth - Azimuth: 70 degrees
3 dB Beamwidth - Elevation: 6 degrees
Front-to-Back Ratio: 30 dB minimum
Polarization: 2X Horizontal, 2X Vertical
Coverage: 90 degrees
Antenna Body Dimensions: 23.4" (H) x 9.6" (W) x 3.25" (D) / 594 mm x 157 mm x 110 mm
Antenna Body Weight: 8.0 lbs / 3.7 kg
Total Weight with AP and Mounting Brackets: 13.8 lbs
Mast Diameter Compatibility: 2" to 4" (5 cm to 10 cm)
Electrical Downtilt: 2 degrees
Technology: 4x4 MU-MIMO
