Cisco Catalyst 9400 Series 10 slot chassis Fan Tray (Spare)
Specification
16 individual fans (four rows)
Minimum airflow: 1190 CFM at 100% fan throttle
Heat dissipation: 2654 BTU/hr
AC input power: 778W (allocated)
DC output: 700W (requested)
Side-to-side airflow direction
N+1 fan redundancy
Hot-swappable fans
Internal controller with normal mode and NEBS mode
Barometric sensor for altitude optimization
Individual PWM fan speed control
Acoustic performance: 60dB at 50% load
