The D-Link 5000 Series Data Center Switches are a series of high-performance switches that feature high port density, routing, and ultra-low latency, designed to be deployed as Top-ofRack (ToR) or leaf-spine switches in data center applications. Combined with ONIE support and increased cost-efficiency, the 5000 Series form a flexible long-term solution for managing and expanding data center infrastructures in a Software-defined Networking (SDN) environment.
RJ-45 Ports: 0
RJ-45 Speeds: 0
Combo Ports (RJ-45 + SFP): 48 (10G) SFP+, 6 (40G) QSFP+ and 1 USB 2.0 Port
SFP (Small Form-Factor Pluggable) Ports : 54
SFP Speeds: 10G , 40G
PoE++ (60w) or higher available?: No
Number of PoE Ports: 0
Extended PoE?: No
Capacity in Millions of Packets per Second (mpps): Maximum Forwarding Rate: 1,071
Switching Capacity in Gigabits per Second (Gbps): 1.44 Tbps
Web-based GUI: No
Redundant Power Supply: Yes
19" Rack Mountable: Yes
DIN-Rail Mountable: No
Stacking Capacity (Physical): No
Stacking Capacity (Virtual): No
IPv4 Routing: Yes
IPv6 Routing: Yes
DHCP (Dynamic Host Configuration Protocol) Server Screening: Yes
Ruggedized: No
Operating Temperature: 0 to 45 C
Unit dimensions: 440 x 406 x 44 mm
Warranty Licence: LIFETIME
