Eaton 9PX EBM 180V (For use with 9PX 5kVA & 6kVA UPS)

The Eaton 9PX EBM 180V is an extended battery module that provides additional runtime for compatible 5kVA and 6kVA Eaton 9PX UPS systems. It features sealed lead-acid batteries in a compact 3U form factor supporting both rack and tower installation.

Battery Type: Sealed Lead-Acid (VRLA) Battery Voltage: 180V DC Number of Batteries: 2 Battery Capacity: 12V / 5Ah per battery Form Factor: 3U Rack/Tower Dimensions: 64.5cm (W) x 44cm (H) x 13cm (D) Weight: 68 kg Mounting: 19-inch EIA standard rack (4-post rail kit included), tower installation with included support stands Installation: Heavy-gauge cabling with high-current 180V DC connectors Daisy-Chain Capability: Up to 4 matching units maximum Certifications: CE Marked, TUV Listed, cULus Listed, CSA 22.2, IEC/EN 62040-1, UL 1778, IEC/EN 62040-2, EAC
