Cisco GRWIC-D-ES-2S-8PC Service Module - 8 x RJ-45 10/100Base-TX Auto-sensing/Auto-negotiating/Auto MDI/MDI-X LAN, 1 x RJ-45 10/100/1000Base-T Auto-sensing/Auto-negotiating/Auto MDI/MDI-X Network

Cisco Ethernet Switch Module for the 2010 Connected Grid Router, featuring 8 x 10/100Base-TX PoE ports and 1 x 10/100/1000Base-T dual-purpose Gigabit Ethernet uplink. Designed for space-constrained environments requiring integrated routing and switching capabilities.

Ports: 8x 10/100Base-TX Fast Ethernet (4 PoE+ capable), 1x Dual-purpose Gigabit Ethernet (10/100/1000Base-T) Memory: 256MB DDR2 SDRAM MAC Address Table: 4000 entries Bandwidth: 8 Gbps Data Transfer Rate: 1 Gbps Forwarding Rate: 5.6 Mpps PoE Support: IEEE 802.3af (up to 15.4W per port) and IEEE 802.3at (up to 30W PoE+ per port) Features: VLAN, QoS, ACL support, SNMP management, RSTP/MSTP support, DHCP snooping Management: CLI, SNMP 1/2/2c/3, RMON, TFTP Compatibility: Cisco 2010 Connected Grid Router (CGR 2010)
